The DTECH DT-7144A HDMI Splitter allows a single HDMI source to be displayed on four HDMI-compatible screens without signal degradation. It supports a wide range of resolutions, including 4K Ultra HD, and is compatible with various audio formats. The splitter is designed for easy setup and operation, making it a versatile solution for both residential and commercial use.
Features
- 4K Ultra HD Support: Distributes high-definition 4Kx2K (3840×2160) @ 30Hz resolution signals to four displays simultaneously.
- Multiple Output Displays: Connects one HDMI source to four HDMI displays, providing identical output on each screen.
- High Bandwidth: Supports data transfer rates up to 10.2 Gbps, ensuring smooth and high-quality video transmission.
- Deep Color and 3D: Supports 36-bit Deep Color and 3D video formats for enhanced video quality and immersive experiences.
- Audio Formats: Compatible with various audio formats, including LPCM, Dolby-AC3, DTS7.1, and DSD, ensuring high-fidelity sound.
- Plug and Play: Simple installation with no need for additional software or drivers.
- LED Indicators: Provides LED indicators for power and signal status, making it easy to monitor the device’s operation.
- Compact and Durable: Small form factor with a sturdy metal casing for durability and efficient heat dissipation.
Specifications
- HDMI Version: HDMI 1.4
- Maximum Resolution: 4Kx2K @ 30Hz (3840×2160)
- Bandwidth: 10.2 Gbps
- Supported Video Formats: 3D, 36-bit Deep Color
- Supported Audio Formats: LPCM, Dolby-AC3, DTS7.1, DSD
- Input Port: 1 x HDMI Type A (Standard)
- Output Ports: 4 x HDMI Type A (Standard)
- Power Supply: 5V DC, 1A
- Power Consumption: < 5W
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -20°C to 70°C (-4°F to 158°F)
- Humidity: 20% to 90% RH (non-condensing)
- Dimensions: 178mm x 59mm x 19mm (7.01in x 2.32in x 0.75in)
- Weight: Approx. 300g (10.58oz)
Package Contents
- 1 x DTECH DT-7144A 4Kx2K HDMI Splitter
- 1 x Power Adapter (5V DC, 1A)
- 1 x User Manual
The DTECH DT-7144A 4Kx2K HDMI Splitter 1×4 is an efficient and reliable solution for distributing high-definition video and audio from a single HDMI source to multiple displays, suitable for a variety of applications that demand high-quality signal distribution.
