DTECH DT-7442 4k HDMI Matrix 4 To 2

The DTECH DT-7442 HDMI Matrix enables users to connect four HDMI sources and independently route any input to either of the two HDMI output displays. This device provides seamless switching and high-quality signal transmission, making it an ideal solution for environments where multiple HDMI sources need to be managed and distributed efficiently.

Features

1. 4K Ultra HD Support: Supports 4Kx2K (3840×2160) @ 30Hz resolution, delivering stunning video quality.
2. Matrix Switching: Allows any of the four HDMI input sources to be routed to either of the two HDMI output displays independently.
3. High Bandwidth: Supports data transfer rates up to 10.2 Gbps, ensuring smooth and high-quality video transmission.
4. Deep Color and 3D: Supports 36-bit Deep Color and 3D video formats for enhanced video quality and immersive experiences.
5. Audio Formats: Compatible with various audio formats, including LPCM, Dolby-AC3, DTS7.1, and DSD, ensuring high-fidelity sound.
6. Control Options: Includes IR remote control and front panel buttons for easy switching between input sources and outputs.
7. LED Indicators: Provides LED indicators for power, input, and output status, making it easy to monitor the device’s operation.
8. Compact and Durable: Sturdy metal casing for durability and efficient heat dissipation.
9. EDID Management: Supports EDID management for improved compatibility with various display devices.

Specifications

• HDMI Version: HDMI 1.4
• Maximum Resolution: 4Kx2K @ 30Hz (3840×2160)
• Bandwidth: 10.2 Gbps
• Supported Video Formats: 3D, 36-bit Deep Color
• Supported Audio Formats: LPCM, Dolby-AC3, DTS7.1, DSD
• Input Ports: 4 x HDMI Type A (Standard)
• Output Ports: 2 x HDMI Type A (Standard)
• Control Method: IR remote control and front panel buttons
• Power Supply: 5V DC, 2A
• Power Consumption: < 10W
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -20°C to 70°C (-4°F to 158°F)
• Humidity: 20% to 90% RH (non-condensing)
• Dimensions: 220mm x 105mm x 25mm (8.66in x 4.13in x 0.98in)
• Weight: Approx. 600g (21.16oz)

Package Contents

• 1 x DTECH DT-7442 4K HDMI Matrix
• 1 x Power Adapter (5V DC, 2A)
• 1 x IR Remote Control
• 1 x User Manual

The DTECH DT-7442 4K HDMI Matrix 4 to 2 offers a flexible and reliable solution for managing multiple HDMI sources and distributing high-quality video and audio to multiple displays, making it an ideal choice for both residential and professional AV applications.
