- – Fixing on portaconverter : 40mm
- – Polarity: H/V Suogni output
- – Direct connection up to 8 different utilities (Decoder or SAT TV)
- – Noise factor: 0.3dB
- – Earning: 55dB
- – Band switching tone: 22Hz
- – Polarity switching V/H: 13/18V
- – Absorption: 200mA
- – Kubassa/high reception: 10.7-11.7-11.7-12GHz
- – Output to the receiver in Ku low/high:950-1.950/1.100-2.150MHz
| Fixing on converter holders | Forty per cent per cent |
|---|---|
| Polarity | H / V each output |
| Direct connection for | 8 different decoders (8 users) |
| Noise factor | 0.3 dB |
| Gain | 55 dB |
| Band switching tone | 22 Hz |
| Polarity switching V/H | 13/18 V |
| Absorption | 200 mA |
| Low / high KU reception | 10.7-11,7-11,7-12.75 GHz |
| Low/high Ku receiver output | 950-1950 / 1100-2150 MHz |
